Breasy
A heater blower series available in various configurations for installation in vehicles such as buses, boats and heavy construction equipment.
A heater blower series available in various configurations for installation in vehicles such as buses, boats and heavy construction equipment.
Breasy is available in 3kW, 7kW and 12kW capacities, 12 or 24V radial fans and 16/19/22mm hose connections to suit your vehicle. The blower can be fitted with a closed mesh dust filter on the intake side as well.
The heat exchangers and the sidewalls of the blower are aluminium, and the endpieces are plastic. All of our Breasy blowers are supplied with an airbleeder for de-aeration.
Art no | Power (kW) | Voltage (VDC) | Air flow (m³/h) | Pipe Ø (mm) |
---|---|---|---|---|
BR312/16 | 3 | 12 | 250 | 16 |
BR312/19 | 3 | 12 | 250 | 19 |
BR312/22 | 3 | 12 | 250 | 22 |
BR324/16 | 3 | 24 | 250 | 16 |
BR324/19 | 3 | 24 | 250 | 19 |
BR324/22 | 3 | 24 | 250 | 22 |
BR712/16 | 7 | 12 | 350 | 16 |
BR712/19 | 7 | 12 | 350 | 19 |
BR712/22 | 7 | 12 | 350 | 22 |
BR724/16 | 7 | 24 | 350 | 16 |
BR724/19 | 7 | 24 | 350 | 19 |
BR724/22 | 7 | 24 | 350 | 22 |
BR1212/16 | 12 | 12 | 750 | 16 |
BR1212/19 | 12 | 12 | 750 | 19 |
BR1212/22 | 12 | 12 | 750 | 22 |
BR1224/16 | 12 | 24 | 750 | 16 |
BR1224/19 | 12 | 24 | 750 | 19 |
BR1224/22 | 12 | 24 | 750 | 22 |
The first digits of the article code refer to the capacity and voltage, the last two refer to the connection diameter.
